48 Volt JLG Articulating Boom Charger i4818-OBRMJLGS400A
Drop-in ready JLG lift charger for E400A, E400AN, E400AJ, E450A, E400AJP, and E450AJP. The advanced i4818OBRMJLGS400A Delta Volt equipped charger is a 48 volt 18 amp made by Pro Charging Systems.
Compatible With These Manufacturers Units:
JLG Articualting Boom Lifts Model Numbers E400A, E400AN – JLG Battery Charger Part Number 1400196 (Mac Battery Charger)
JLG Articualting Boom Lifts Model Numbers E400AJ, E450A – JLG Battery Charger Part Number 1001123054 (Delta-Q Battery Charger) Note: Serial Number 144567 to Now for Part Number 1001123054
JLG Articulating Jib Plus Lifts Model Numbers E400AJP, E450AJP – JLG Battery Charger Part Number 0400196 (MAC Battery Charger)
Eagle Performance Battery Charging Systems are designed for the demands of the industrial lift industry
One of the keys to developing the best battery performance is bringing batteries up to the proper specific gravity levels as recommended by battery manufacturers. Pro Charging Systems, LLC (PCS) manufactures the only chargers that will consistently recharge batteries to a 100% level.
By bringing a battery’s electrolyte to this charge level and in turn the proper specific gravity level, PCS chargers significantly reduce sulfation, which is a primary cause of premature battery failure.
The charging profile results in over 25% more discharge time for the customer and much better service life. They provide a very fast recharge time, reaching absorption levels in virtually the same amount of time as their fastest competitors. They then take batteries to a “finishing” level while their competitors have already terminated their charge profile or ended in a float stage.
JLG i4818-OBRMJLGS400A Charger Features:
- Get wireless connectivity with DeltaView Link
- Keep batteries performing better over time
- 25% More discharge time
- Better service life
This UL 1564L listed battery charger is perfect for fleet operators needing to track and monitor employee operations. The exclusive on board diagnostics tool records the last 83 charge profiles and will assist in determining if there is a battery issue or personnel issue such as prematurely taking the vehicle off the charger before being fully charged.
| Brand | Dual Pro |
|---|---|
| Model | i4818OBRMJLGS400A |
| Chemistry | Lead Acid |
| Input Frequency (Hz) | 60 |
| Voltage (VDC) | 48 |
| Input Voltage (VAC) | 120 |
| Output Voltage - Charging (V) | 60 |
| Output Voltage - Float (V) | 54 - Shuts Off |
| Output Banks | 1 |
| Max DC Current (A) | 18 |
| Operating Temp. Range (oC) | 32-115 |
| Warranty | 18 Month |
| Dimensions (LxWxH - metric) | 229 x 216 x 146 |
| Weight (lb) | 28 |
| Dimensions (LxWxH - inches) | 9 x 8.5 x 5.75 |
