i1225-OB Dual Pro Industrial Charger 12 Volt 25 Amp
This is the 12 volt 25 amp i1225-OB Dual Pro Eagle On-board charger with Delta Volt technology by Pro Charging Systems.
Eagle Performance Series On Board chargers are specially designed for use in the industrial and electric vehicle markets. With over 18 years of experience in manufacturing the legendary Dual Pro charging systems, Pro Charging Systems chargers have become known as THE name in charging technologies. They pride themselves on the performance and versatility of their products and outstanding customer service. These safe, reliable, and efficient battery chargers are made in the USA.
All Eagle Performance Series units have reverse polarity protection, on board fan cooling, temperature control and Quick Logic microprocessor capabilities. This unit comes with eyelets and can be ordered with the industry standard 50 amp Anderson SB50 connector.
- Fully Automatic and Water Resistant
- TROUBLE FREE - Just Plug It In and Forget It!
- Unmatched Performance, Reliability, Safety and Quality
- The Green Charger: Totally Repairable Not a Throw-Away
| Availability Note | Discontinued - New Model ETA June 2021 |
|---|---|
| Brand | Dual Pro |
| Model | i1225-OB |
| Chemistry | Lead Acid |
| Input Frequency (Hz) | 60 |
| Voltage (VDC) | 12 |
| Input Voltage (VAC) | 120 |
| Output Voltage - Charging (V) | 14.5 |
| Output Voltage - Float (V) | 13.5 - Shuts Off |
| Output Banks | 1 |
| Max DC Current (A) | 25 |
| Operating Temp. Range (oC) | 32-115 |
| Warranty | 3 Year |
| Dimensions (LxWxH - metric) | 229 x 216 x 222 |
| Weight (lb) | 19 |
| Dimensions (LxWxH - inches) | 9 x 8.50 x 8.75 |
